3 Pcs Go Kart Drive Belt 203591 Q4302W 30 Series Compatible with Yerf Dog Q430203W Q43103W Q43203W Manco Carter 5.5hp 6.5hp Kartco 7655 Rotary 12-10052 Belt Replace 3203 3002 Go Kart
Interchange part number: 203591 / Q430203W. Universal Q430203W Go Cart Belt 30 Series for Compatible with Yerf Dog.
Compatible with Yerf Dog Go Kart Q43103W Model 3002 3200 3202 3203 Replace Manco 203591 5.5hp 6.5hp Kartco 7655 Rotary 12-10052.
Size:
Width: 0.75 inch / 19mm(approx).
Length: 29.28 inch / 744mm(approx).
Angles are different on each side of belt, one side of the belt is almost flat measuring 2 1/2 degrees and 18 degrees on other side.
Pulley needs to be from 7 9/16 inch to 7 5/8 inch(6 Driven), or from 6 13/16 to 6 7/8 inch(7 Driven) (measured from the center of the clutch to the center of the driven pulley).
